PRODUCT PARAMETERS
Description
- Product Features:
Powerful Drilling Capabilities：
Equipped with a high-torque rotary head, the MX800 can penetrate various soil types and rock formations, ensuring optimal productivity.
Capable of reaching depths of up to 800 meters with a drilling diameter range of 140mm to 305mm.
Hydraulic System：
Advanced hydraulic components provide precise control and enhanced efficiency during drilling operations.
The system ensures smooth operation and reduces maintenance requirements, prolonging the rig’s lifespan.
User-Friendly Design：
Ergonomically designed control panel allows for easy operation and monitoring.
Modular components simplify assembly, transportation, and on-site setup.
Durability and Reliability：
Constructed with high-strength steel and corrosion-resistant materials to withstand harsh environmental conditions.
Features a reinforced chassis for added stability during drilling.
Energy Efficiency：
Equipped with a fuel-efficient engine that minimizes operational costs while delivering consistent performance.
Includes an advanced power management system to optimize energy usage.
Versatility：
Suitable for a wide range of applications including agricultural irrigation, municipal water supply, and industrial projects.
Compatible with various drilling tools and accessories to adapt to specific project needs.
2. Product Applications：
The MX800 Water Well Drilling Rig is ideal for:
Drilling water wells in urban and rural settings.
Constructing geothermal wells for sustainable energy solutions.
Supporting mining exploration and geological surveys.
Facilitating irrigation systems for agricultural development.
3. Product Parameter：
| MX800 Water Well Drilling Rig | |||
| The weight（T） | 13 | Drill pipe diameter（mm） | Φ102 Φ108 Φ114 |
| The hole diameter（mm） | 140-400 | Drill pipe length（m） | 1.5m 2.0m 3.0m 6.0m |
| Drilling depth（m） | 800 | Rig lifting force（T） | 30 |
| One-time advance length（m） | 6.6 | Rapid rise speed（m/min） | 20 |
| Walking speed（km/h） | 2.5 | Fast feeding speed（m/min） | 40 |
| Climbing angles（Max.） | 30 | Width of loading（m） | 2.95 |
| Equipped capacitor（kw） | 153 | Hoisting force of winch（T） | 2 |
| Using air pressure（MPA） | 1.7-3.5 | Swing torque（N.m） | 8850-13150 |
| Air consumption（m³/min） | 17-42 | Dimension（mm） | 6300×2300×2950 |
| Swing speed（rpm） | 45-140 | Equipped with hammer | Medium and high wind pressure series |
| The penetration efficiency（m/h） | 15-35 | High leg stroke（m） | 1.7 |
| The engine brand | Cummins engine | ||
FAQs
What types of products can we offer?
- Applications: Designed for drilling water wells in various geological conditions (soft soil, sand, gravel, and hard rock).
- Features:
- Compatible with air compressors or mud pumps for efficient drilling in diverse terrains.
- High mobility with trailer/truck-mounted configurations for remote site access.
- Typical drilling depth: 100–500 meters, adaptable to regional requirements.
- Advantages: Energy-efficient, user-friendly controls, and modular design for easy maintenance.
- Applications: Geological exploration (metal/non-metal mineral surveys), hydrogeological studies, and oil/gas field exploration.
- Features:
- Rope coring technology for precise sample extraction.
- Hydraulic systems for stable operation in challenging environments.
- Drilling diameter: 50–150 mm; depth up to 1,000 meters.
- Advantages: High core recovery rate, low vibration, and compatibility with wireline drilling systems.
3. DTH (Down-the-Hole) Drilling Rig
- Applications: Ideal for hard rock formations in mining, quarrying, and geothermal projects.
- Features:
- Pneumatic hammer drills for rapid penetration.
- Adjustable air pressure (1.7–3.5 MPa) and customizable hole diameters (102–114 mm).
- Supports depths up to 300 meters.
- Advantages: Reduced deviation, high drilling speed, and minimal wear on tools.
4. HDD (Horizontal Directional Drilling) Rig
- Applications: Underground pipeline/utility installation without trenching, suitable for urban areas and river crossings.
- Features:
- GPS-guided steering systems for precision.
- Torque capacity: 10,000–30,000 Nm; pullback force up to 200 tons.
- Drilling length: 100–2,000 meters.
- Advantages: Environmentally friendly, minimal surface disruption, and adaptable to varying soil types.
5. Excavator Mounted Drilling Rig
- Applications:
Mining and Quarry Drilling:Efficient for blast hole drilling in open-pit mines, quarries, and aggregate extraction sites.
Slope Stabilization and Anchoring:Ideal for drilling anchor holes on slopes, embankments, and landslide-prone areas to install rock bolts and soil nails.
Foundation and Piling Work：Used for drilling foundation holes in urban construction, bridges, retaining walls, and infrastructure projects.
- Feature:Easily converts your excavator into a powerful and flexible drilling rig for rock, soil, and foundation applications.
Key Selling Points:
Compliance: Meets international standards (ISO, CE) and adapts to local regulations (e.g., EU VAT, environmental policies).
Customization: Tailored configurations (e.g., crawler/wheel-mounted) to meet project-specific needs .
After-Sales Support: 24/7 technical assistance, regional service centers, and extended warranty options .
What logistics do we ship through?
We offer high-efficiency logistics solutions and secure delivery of heavy-duty drilling equipment. Here’s how we handle shipments:
Support EXW, FOB, CIF, DDP, etc., tailored to your needs.
Transportation Options
Sea Freight: Cost-effective for large machines (e.g., rigs exceeding 10 tons). Suitable for long-distance international shipments. Delivery time: 25–45 days1.
Air Freight: Fast-track delivery for urgent orders or spare parts. Delivery time: 3–10 days1.
Land Freight: Ideal for regional deliveries (e.g., within Asia or Europe). Includes truck or rail transport.
Multimodal Solutions: Combined sea/air/land transport for optimized cost and efficiency.
Packaging & Safety
Heavy machinery is securely packed with steel frames, weatherproof wooden crates, and anti-rust treatments1.
Fragile components (e.g., hydraulic systems) are individually padded and labeled.
Customs & Documentation
We provide full export documentation (commercial invoice, packing list, COO, etc.) and assist with customs clearance globally.
Delivery Assurance
Real-time tracking: Monitor shipments via our logistics platform.
Insurance coverage: Optional all-risk insurance for high-value equipment.
Flexible Trade Terms
Can it be customized as per our requirements?
Yes, mechanical equipment can be fully customized to meet your specific requirements. Here’s a structured overview:
1. Customization Scope
- Functional Adaptations: Tailored to your operational needs (e.g., power output, precision, automation level) .
- Design Modifications: Adjustments in size, material, and ergonomic layout to fit your workspace.
- Integration Capabilities: Compatibility with existing systems (e.g., IoT sensors, production line interfaces).
2. Key Benefits
- Optimized Efficiency: Custom designs align with your workflow, reducing downtime and energy waste.
- Cost Savings: Eliminate unnecessary features while prioritizing critical functionalities.
- Competitive Edge: Unique equipment enhances product quality and differentiation in your market.
3. Process Overview
- Consultation: Detailed analysis of your needs and operational environment.
- Prototyping: 3D modeling and testing to validate design feasibility.
- Production: Advanced manufacturing techniques (e.g., CNC machining, laser cutting) ensure precision.
- Post-Sale Support: Installation, training, and maintenance services included.
4. Industries Served
- Heavy machinery, automotive, aerospace, and precision engineering sectors.
For a tailored solution, collaborate with a specialized manufacturer to discuss technical specifications and project timelines. Let us know your requirements—we’ll handle the rest!
